•Meets medical & LED driver safety
•2 MOPP input to output isolation
•Touch current ≤ 100μA
•Earth Leakage current ≤ 5mA
•Energy efficiency level VI
•PF>0.95@230VAC full load
• ≤0.15W standby power
•11V-48V outputs, up to 200W
•Up to 5,000m operating altitude
•4 types of AC inlet
| Model Number | Voltage (V) | Current (A) | Rated Power | Ripple & Noise (Max) | Voltage Tolerance | Line& Load Regulation | Efficiency (Average) | Start Up delay |
UES200-XXXYYYSPAZ | 11.0-12.0 | 0.01-15.0 | 180.00W | 150mVpk-pk | ±5% | Line: ±1 % Load: ±5% | 89.0% | ≤3s |
12.1-13.0 | 0.01-14.0 | 182.00W | 150mVpk-pk | ±5% | 89.0% | ≤3s | ||
13.1-14.0 | 0.01-13.5 | 190.00W | 150mVpk-pk | ±5% | 89.0% | ≤3s | ||
14.1-15.0 | 0.01-13.3 | 200.00W | 150mVpk-pk | ±5% | 89.0% | ≤3s | ||
15.1-48.0 | 0.01-12.5 | 200.00W | 180mVpk-pk | ±5% | 89.0% | ≤3s |
Input Voltage Range | 90-264VAC |
| Frequency Range | 47-63Hz |
| Input Current | 2.5A at 90VAC |
| Inrush Current | 120A max at 240VAC cold start |
| Touch Leakage Current(Max) | Class I & Class II≤100μA at 264VAC |
Dimensions(mm) | 210(L)x85(W)x42(H)mm |
| Weight | 950g |
| MTBF | ＞100,000hrs MIL-HDBK-217 at 25°C |
| Overload | 120-170% rated output power, auto recovery |
| Over Voltage | 120-150% rated output voltage input to reset |
| Short Circuit | Trip and restart (hiccup mode) |
| Safety Agency / Mark | Medical | ITE |
| CB | IEC61347 | IEC60601-1 |
| UL | UL8750 | ANSI/AAMI ES60601-1 CAN/CSA-C22.2 NO. 60601-1 |
| TṻV-SUD/Mark | EN 61347 | EN60601-1 |
| CE | EN61347 | - |
| Emissons | Lamp | Medical |
| Conduction | EN 55015,CISPR 15 | IEC/EN60601-1-2.CISPR 11 |
| Radiation | EN 55015,CISPR 15 | IEC/EN60601-1-2.CISPR 11 |
| Harmonic Currents | EN61000-3-2, Class C | EN61000-3-2, Class A |
| Voltage Flicker | EN61000-3-3 | EN61000-3-3 |
| Immunity | IEC/EN61547 | IEC/EN60601-1-2 |
| ESD | IEC61000-4-2 | ±15KV air,±8KV contact |
| Radiated Immunity | IEC61000-4-3 | 10V/m ,3V/m 80MHz - 2.7GMHz |
| EFT/Burst | IEC61000-4-4 | ±2KV on AC port, ±1KV on signal ports |
| Surge | IEC61000-4-5 | ±1KV line to line (different mode) |
| Conducted Immunity | IEC61000-4-6 | 3Vrms, 6Vrms (0.15MHz-80MHz) |
| Magnetic Field | IEC61000-4-8 | 30 A/m |
Dips & Interruptions | IEC61000-4-11 | 0%, 70%, 0% of UT |
| Dielectric Withstand Voltage | 5,656VDC input to output |
| Insulation Resistance | 10M Ohms, 500VDC input to output |
